Quick Details

  • Brand Name: MINE
  • Model Number: HD100U
  • Place of Origin: Guangdong, China (Mainland)
  • Model: HD100U
  • Input Interface: 1 HDMI
  • size: 84.25x42.8x12.6 (L/W/H, mm)
  • weight: 0.2kg
  • website: www.szminetech.com
  • CE.FCC: YES
  • package: in gift box
  • high resolution: Support up to 1920x1200p60 (CVT-RB) Video Input
  • Country of origin: china,shenzhen
  • warranty: 1 year

Packaging & Delivery

Packaging Details: Kraft paper carton or neutral packing
Delivery Detail: 5-7 days
High Linux quality(HD100U) usb 3.0 HD video capture device




 HD100U Specification

Product Features

*It can capture one single channel HD HDMI video signals.

*The input and output video signal can reach 1080p/60 Hz.

*It is compatible with UVC video capture and YUV 422 video output.

*The UAC is compatible with HDMI audio capture and 48 KHz PCM audio output.

*It doesn’t need to install a driver, and it is truly PnP.

*It is compatible with Windows, Linux, OS X operating systems.

*size : 92.2 x 40.2 x 12.3 (L/W/H, mm).

*USB3.0, 300-350MB/s throughput and it is compatible with USB 2.0.

*The process of video and audio is done by the dongle and will not occupy the CPU.

*It can automatically detect the input video formats and it will adjust to the set output size and frame rate automatically.

*It can automatically detect the input audio formats and swift it to 48KHz PCM audio.

*It supports the image adjustment features, like brightness, contrast, hue and saturation.

*Multiple dongles can be used on one PC

*The firmware can be updated.



Product Specification

Connection

Host Interface

USB3.0, *300-350MB/s throughput

USB2.0, *40MB/s throughput

Input Interface

1 HDMI interface

HDMI Input

1 1080P/60HzHD HDMI

HDMI Audio Input

1 LPCM audio signal

Standards

HDMI Input Formats

It meets the HDMI 1.4a standard, and supports 080p/60Hz 8-bit, (RGB, YUV)

Output Formats

Resolutions: 640x480/720x480/720x576/768x576/800x600/1024x768/ 1280x720/1280x800/1280x960/1280x1024/1368x768/1440x900/1600x1200/1680x1050/1920x1080/1920x1200

frame rate: 25/29.97/30/50/59.94/60 fps

Video Sampling Rate

HDMI: 165MHz

Audio and video capture

It meets the standards of UVC (USB video class) and UAC(USB audio class)

Output color space

YUY2, RGB24

Video Process

Color space switch

Hardware Color Space Switch

Image Scale

Hardware scale

Image Adjustment

The image adjustment of brightness, contrast, hue, saturation.

Others

The support of OS

It supports the following operating systems (x86 and x64 versions):

Windows 7

Windows Server 2008 R2

Linux (Kernel version 2.6.38 and above)

OS X (10.8 and above)

Software compatibility

Windows Media Encoder (Windows)

Adobe Flash Media Live Encoder (Windows, OS X)

Real Producer Plus (Windows)

VLC (Windows, OS X, Linux)

QuickTime Broadcaster (OS X)

QuickTime Player (OS X)

Wirecast (Windows, OS X) and etc.

Development interface compatibility

DirectShow (Windows), DirectSound (Windows),

V4L2 (Linux), ALSA (Linux)

OS X (QuickTime)

Onboard memory

64MB DDR2, the work rate is 300 MHz, the bit width is 16 bits

Upgrade

the firmware can be upgraded

Size

84.25x42.8x12.6 (L/W/H, mm)

Power consumption

<= 2.5W

Working Temperature

0-50 deg C

Storage Temperature

-20-70 deg C

Storage Humidity

5%-90%

Please note:

1.   The actual USB 3.0 throughput is related to the chip of the host and motherboard of the PC and the figure shall be lower than the figure stated here.



 Incredible Compatibility



Compatible with various USB 3.0 chipsets (Intel, Renesas, ASMedia, Fresco Logic), compatible with expended USB 3.0 via PCIe Gen1.1 x1

  • Compatible with USB 2.0
  • Compatible operating systems: Windows (7, 8, 8.1), Linux (kernel version 2.6.38 and above), OS X (10.8 and above)





  • Support APIs, such as Windows: DirectShow, DirectSound, Linux: V4L2, ALSA, OS X: QuickTime
  • Support software including Windows Media Encoder (Windows), Adobe Flash Media Live Encoder (Windows, OS X), Real Producer Plus (Windows), VLC (Windows, OS X, Linux), QuickTime Broadcaster (OS X), QuickTime Player (OS X), Wirecast (Windows, OS X) and etc…



Excellent Video Processing

  • Support up to 1920x1200p60 (CVT-RB) Video Input
  • Video output support up to 1920x1200p60 in YUY2
  • Video output support up to 1920x1200p60 in RGB24
  • The process of video and audio is done by the dongle and will not occupy CPU.



Flexible and Friendly Features

  • Connect multiple dongles to one machine
  • Enable the up/down conversion of video resolution, frame rate and audio sampling rate
  • Support brightness, contrast, hue, saturation, and other screen adjustment functions



  • The HDMI video capture meets UVC standard, support YUV 4:2:2 (YUY2) or RGB 4:4:4 (RGB24) video output
  • The HDMI video capture meets UAC standard and 48KHz PCM stereo audio output
  • The video processing engine can be updated via firmware without changing the hardware.
  • Automatically detect and de-interlace signals





Easy to Use

  • No need to install drivers in Windows, Linux, and OS X, real plug and play.
  • Automatically determine the input video format and automatically convert it to the specified output size and frame rate.
  • Automatically determine the input audio formats and automatically convert it to 48 KHz PCM stereo audio.



Reliable and Stable

  • 64MB DDR2 Onboard memory, it can effectively conduct video frame buffer and USB transfer flow control to avoid interruption or error images when the USB transmission bandwidth is occupied.
  • Pass through 7x24h continuous high load tests in high and low temperatures (0-50 degrees)
